Acme Electric Buck Boost Transformer

Product Inquiry

SKU: ACM T181059

Select Variant: STANDARD

Prismecs Value-Added Services

Interested in Prismecs' EPC services? Check the box(es) below for your selection. Our support team will contact you.

Operations and Maintenance

Installation and Commissioning

Other

The Acme Electric Buck Boost Transformer is an encapsulated transformer designed for efficient voltage conversion in various applications. Its robust construction and reliable performance make it suitable for both commercial and industrial environments.

Key Features:

Voltage Ratings: 120/240 VAC primary; 16/32 VAC secondary.
Power Rating: 0.75 kVA, providing reliable power delivery.
Frequency: Operates at both 50 and 60 Hz for versatile compatibility.
Phase: Single-phase design for ease of integration.
Maximum Current: 46.9 A (primary) / 23.4 A (secondary) for flexible load management.
Connection Type: Wire lead screw connection for straightforward installation.
Construction: Encapsulated design with steel housing for durability.
Insulation Rating: Class H insulation rated for 180 °C, ensuring thermal stability.
NEMA Rating: NEMA 3R enclosure, offering protection against dust and moisture ingress.

Brand Name	Hubbell

Weight	19 lb
Dimensions (L x W x H)	9.68 x 4.75 x 4.51 in
